TK4R3A06PL,S4X

Part No :: TK4R3A06PL,S4X

Manufacturer: Toshiba Electronic Devices and Storage Corporation

Description: MOSFET N-CH 60V 68A TO220SIS

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: TK4R3A06PL,S4X PDF

Availability: 50 pieces

Current price of TK4R3A06PL,S4X is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TK4R3A06PL,S4X Specifications

Type	Description
Series:	U-MOSIX-H
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	68A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	7.2mOhm @ 15A, 4.5V
Vgs(th) (Max) @ Id:	2.5V @ 500µA
Gate Charge (Qg) (Max) @ Vgs:	48.2 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3280 pF @ 30 V
FET Feature:	-
Power Dissipation (Max):	36W (Tc)
Operating Temperature:	175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220SIS
Package / Case:	TO-220-3 Full Pack
