AOD4504

Part No :: AOD4504

Manufacturer: Alpha and Omega Semiconductor, Inc.

Description: MOSFET N-CH 200V 1.5A/6A TO252

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: AOD4504 PDF

Availability: 0 pieces

Current price of AOD4504 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AOD4504 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	200 V
Current - Continuous Drain (Id) @ 25°C:	1.5A (Ta), 6A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	400mOhm @ 3A, 10V
Vgs(th) (Max) @ Id:	3.7V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	115 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	328 pF @ 100 V
FET Feature:	-
Power Dissipation (Max):	2.5W (Ta), 42.5W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	TO-252, (D-Pak)
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
