NTDV20P06LT4G

Part No :: NTDV20P06LT4G

Manufacturer: VIGOR

Description: MOSFET P-CH 60V 15.5A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NTDV20P06LT4G PDF

Availability: 304683 pieces

Current price of NTDV20P06LT4G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NTDV20P06LT4G Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	15.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	150mOhm @ 7.5A, 5V
Vgs(th) (Max) @ Id:	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	26 nC @ 5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1.19 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	65W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DPAK
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
