AO4286

Part No :: AO4286

Manufacturer: Alpha and Omega Semiconductor, Inc.

Description: MOSFET N-CH 100V 4A 8SOIC

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: AO4286 PDF

Availability: 0 pieces

Current price of AO4286 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AO4286 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	4A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	68mOhm @ 4A, 10V
Vgs(th) (Max) @ Id:	2.9V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	10 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	390 pF @ 50 V
FET Feature:	-
Power Dissipation (Max):	2.5W (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-SOIC
Package / Case:	8-SOIC (0.154", 3.90mm Width)
