IPU80R1K4P7AKMA1

Part No :: IPU80R1K4P7AKMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 800V 4A TO251-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IPU80R1K4P7AKMA1 PDF

Availability: 1469 pieces

Current price of IPU80R1K4P7AKMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IPU80R1K4P7AKMA1 Specifications

Type	Description
Series:	CoolMOS™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	800 V
Current - Continuous Drain (Id) @ 25°C:	4A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	1.4Ohm @ 1.4A, 10V
Vgs(th) (Max) @ Id:	3.5V @ 700µA
Gate Charge (Qg) (Max) @ Vgs:	10.05 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	250 pF @ 500 V
FET Feature:	Super Junction
Power Dissipation (Max):	32W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	PG-TO251-3
Package / Case:	TO-251-3 Short Leads, IPak, TO-251AA
