IRFI9Z24GPBF

Part No :: IRFI9Z24GPBF

Manufacturer: Vishay / Siliconix

Description: MOSFET P-CH 60V 8.5A TO220-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRFI9Z24GPBF PDF

Availability: 2 pieces

Current price of IRFI9Z24GPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRFI9Z24GPBF Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	8.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	280mOhm @ 5.1A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	19 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	570 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	37W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220-3
Package / Case:	TO-220-3 Full Pack, Isolated Tab
