NVMFS5C680NLT1G

Part No :: NVMFS5C680NLT1G

Manufacturer: VIGOR

Description: POWER FIELD-EFFECT TRANSISTOR

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NVMFS5C680NLT1G PDF

Availability: 0 pieces

Current price of NVMFS5C680NLT1G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NVMFS5C680NLT1G Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	8.1A (Ta), 21A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	27.5mOhm @ 7.5A, 10V
Vgs(th) (Max) @ Id:	2.2V @ 13µA
Gate Charge (Qg) (Max) @ Vgs:	5.8 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	330 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	3.4W (Ta), 24W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	5-DFN (5x6) (8-SOFL)
Package / Case:	8-PowerTDFN, 5 Leads
