FDD7030BL

Part No :: FDD7030BL

Manufacturer: VIGOR

Description: MOSFET N-CH 30V 14A/56A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FDD7030BL PDF

Availability: 80423 pieces

Current price of FDD7030BL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDD7030BL Specifications

Type	Description
Series:	PowerTrench®
Package:	Bulk
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	14A (Ta), 56A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	9.5mOhm @ 14A, 10V
Vgs(th) (Max) @ Id:	3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	20 nC @ 5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1.425 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	2.8W (Ta), 60W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D-PAK (TO-252)
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
