TK12A45D(STA4,Q,M)

Part No :: TK12A45D(STA4,Q,M)

Manufacturer: Toshiba Electronic Devices and Storage Corporation

Description: MOSFET N-CH 450V 12A TO220SIS

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: TK12A45D(STA4,Q,M) PDF

Availability: 0 pieces

Current price of TK12A45D(STA4,Q,M) is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TK12A45D(STA4,Q,M) Specifications

Type	Description
Series:	π-MOSVII
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	450 V
Current - Continuous Drain (Id) @ 25°C:	12A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	520mOhm @ 6A, 10V
Vgs(th) (Max) @ Id:	4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	24 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	1200 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	45W (Tc)
Operating Temperature:	150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220SIS
Package / Case:	TO-220-3 Full Pack
