RJK0366DPA-00#J0

Part No :: RJK0366DPA-00#J0

Manufacturer: VIGOR

Description: MOSFET N-CH 30V 25A 8WPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: RJK0366DPA-00#J0 PDF

Availability: 19800 pieces

Current price of RJK0366DPA-00#J0 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

RJK0366DPA-00#J0 Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	25A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	-
Rds On (Max) @ Id, Vgs:	11.1mOhm @ 12.5A, 10V
Vgs(th) (Max) @ Id:	-
Gate Charge (Qg) (Max) @ Vgs:	6.8 nC @ 10 V
Vgs (Max):	-
Input Capacitance (Ciss) (Max) @ Vds:	1.01 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	30W (Tc)
Operating Temperature:	150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-WPAK
Package / Case:	8-PowerWDFN
