IRLR7843PBF

Part No :: IRLR7843PBF

Manufacturer: VIGOR

Description: HEXFET POWER MOSFET

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRLR7843PBF PDF

Availability: 16850 pieces

Current price of IRLR7843PBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRLR7843PBF Specifications

Type	Description
Series:	HEXFET®
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	161A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	3.3mOhm @ 15A, 10V
Vgs(th) (Max) @ Id:	2.3V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	50 nC @ 4.5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	4.38 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	140W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D-Pak
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
