2SJ649-AZ

Part No :: 2SJ649-AZ

Manufacturer: Renesas Electronics America

VIGOR # :: 2905707

Description: MOSFET P-CH 60V 20A TO220

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: 2SJ649-AZ PDF

Country of origin: -

Date code: -

2SJ649-AZ Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4V, 10V
Rds On (Max) @ Id, Vgs:	48mOhm @ 10A, 10V
Vgs(th) (Max) @ Id:	-
Gate Charge (Qg) (Max) @ Vgs:	38 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1900 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	2W (Ta), 25W (Tc)
Operating Temperature:	150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220 Isolated Tab
Package / Case:	TO-220-3 Isolated Tab
