NTD24N06LT4G

Part No :: NTD24N06LT4G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET N-CH 60V 24A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NTD24N06LT4G PDF

Availability: 0 pieces

Current price of NTD24N06LT4G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NTD24N06LT4G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	24A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	5V
Rds On (Max) @ Id, Vgs:	45mOhm @ 10A, 5V
Vgs(th) (Max) @ Id:	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	32 nC @ 5 V
Vgs (Max):	±15V
Input Capacitance (Ciss) (Max) @ Vds:	1140 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	1.36W (Ta), 62.5W (Tj)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DPAK
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
