NTD3055L104-1G

Part No :: NTD3055L104-1G

Manufacturer: VIGOR

Description: SINGLE N-CHANNEL LOGIC LEVEL POW

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NTD3055L104-1G PDF

Availability: 0 pieces

Current price of NTD3055L104-1G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NTD3055L104-1G Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	12A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	5V
Rds On (Max) @ Id, Vgs:	104mOhm @ 6A, 5V
Vgs(th) (Max) @ Id:	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	20 nC @ 5 V
Vgs (Max):	±15V
Input Capacitance (Ciss) (Max) @ Vds:	440 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	1.5W (Ta), 48W (Tj)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	I-PAK
Package / Case:	TO-251-3 Short Leads, IPak, TO-251AA
