IRF9540NSTRRPBF

Part No :: IRF9540NSTRRPBF

Manufacturer: IR (Infineon Technologies)

Description: MOSFET P-CH 100V 23A D2PAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRF9540NSTRRPBF PDF

Availability: 0 pieces

Current price of IRF9540NSTRRPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRF9540NSTRRPBF Specifications

Type	Description
Series:	HEXFET®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	23A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	117mOhm @ 14A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	110 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1450 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	3.1W (Ta), 110W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D2PAK
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
