FQB7P20TM

Part No :: FQB7P20TM

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET P-CH 200V 7.3A D2PAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FQB7P20TM PDF

Availability: 1287 pieces

Current price of FQB7P20TM is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FQB7P20TM Specifications

Type	Description
Series:	QFET®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	200 V
Current - Continuous Drain (Id) @ 25°C:	7.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	690mOhm @ 3.65A, 10V
Vgs(th) (Max) @ Id:	5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	25 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	770 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	3.13W (Ta), 90W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D²PAK (TO-263AB)
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
