IRFR120PBF

Part No :: IRFR120PBF

Manufacturer: Vishay / Siliconix

Description: MOSFET N-CH 100V 7.7A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRFR120PBF PDF

Availability: 1033 pieces

Current price of IRFR120PBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRFR120PBF Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	7.7A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	270mOhm @ 4.6A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	16 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	360 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	2.5W (Ta), 42W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D-Pak
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63

Please confirm the specifications of the products when ordering.
