MSC060SMA070B

Part No :: MSC060SMA070B

Manufacturer: Roving Networks / Microchip Technology

Description: SICFET N-CH 700V 39A TO247-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: MSC060SMA070B PDF

Availability: 111 pieces

Current price of MSC060SMA070B is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MSC060SMA070B Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss):	700 V
Current - Continuous Drain (Id) @ 25°C:	39A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	20V
Rds On (Max) @ Id, Vgs:	75mOhm @ 20A, 20V
Vgs(th) (Max) @ Id:	2.4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	56 nC @ 20 V
Vgs (Max):	+23V, -10V
Input Capacitance (Ciss) (Max) @ Vds:	1175 pF @ 700 V
FET Feature:	-
Power Dissipation (Max):	143W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-247-3
Package / Case:	TO-247-3

Please confirm the specifications of the products when ordering.
