BSS138WH6433XTMA1

Part No :: BSS138WH6433XTMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 60V 280MA SOT323-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BSS138WH6433XTMA1 PDF

Availability: 369 pieces

Unit Price: ~~$0.41000~~

Current price of BSS138WH6433XTMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BSS138WH6433XTMA1 Specifications

Type	Description
Series:	SIPMOS™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	280mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	3.5Ohm @ 200mA, 10V
Vgs(th) (Max) @ Id:	1.4V @ 26µA
Gate Charge (Qg) (Max) @ Vgs:	1.5 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	43 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	500mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-SOT323-3
Package / Case:	SC-70, SOT-323
