SI2316DS-T1-E3

Part No :: SI2316DS-T1-E3

Manufacturer: Vishay / Siliconix

Description: MOSFET N-CH 30V 2.9A SOT23-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: SI2316DS-T1-E3 PDF

Availability: 16342 pieces

Current price of SI2316DS-T1-E3 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SI2316DS-T1-E3 Specifications

Type	Description
Series:	TrenchFET®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	2.9A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	50mOhm @ 3.4A, 10V
Vgs(th) (Max) @ Id:	800mV @ 250µA (Min)
Gate Charge (Qg) (Max) @ Vgs:	7 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	215 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	700mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	SOT-23-3 (TO-236)
Package / Case:	TO-236-3, SC-59, SOT-23-3
