IXFH10N100P

Part No :: IXFH10N100P

Manufacturer: Wickmann / Littelfuse

Description: MOSFET N-CH 1000V 10A TO247AD

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IXFH10N100P PDF

Availability: 251110 pieces

Current price of IXFH10N100P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IXFH10N100P Specifications

Type	Description
Series:	HiPerFET™, PolarP2™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	1000 V
Current - Continuous Drain (Id) @ 25°C:	10A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	1.4Ohm @ 5A, 10V
Vgs(th) (Max) @ Id:	6.5V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	56 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	3030 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	380W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-247AD (IXFH)
Package / Case:	TO-247-3
