FDC6392S

Part No :: FDC6392S

Manufacturer: VIGOR

Description: 2.2A, 20V, P-CHANNEL, MOSFET

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FDC6392S PDF

Availability: 119954 pieces

Current price of FDC6392S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDC6392S Specifications

Type	Description
Series:	PowerTrench®
Package:	Bulk
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	20 V
Current - Continuous Drain (Id) @ 25°C:	2.2A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	2.5V, 4.5V
Rds On (Max) @ Id, Vgs:	150mOhm @ 2.2A, 4.5V
Vgs(th) (Max) @ Id:	1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	5.2 nC @ 4.5 V
Vgs (Max):	±12V
Input Capacitance (Ciss) (Max) @ Vds:	369 pF @ 10 V
FET Feature:	Schottky Diode (Isolated)
Power Dissipation (Max):	960mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	SuperSOT™-6
Package / Case:	SOT-23-6 Thin, TSOT-23-6

Please confirm the specifications of the products when ordering.
