FDD16AN08A0_NF054

Part No :: FDD16AN08A0_NF054

Manufacturer: VIGOR

Description: MOSFET N-CH 75V 9A/50A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FDD16AN08A0_NF054 PDF

Availability: 310 pieces

Current price of FDD16AN08A0_NF054 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FDD16AN08A0_NF054 Specifications

Type	Description
Series:	UltraFET™
Package:	Bulk
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	75 V
Current - Continuous Drain (Id) @ 25°C:	9A (Ta), 50A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	6V, 10V
Rds On (Max) @ Id, Vgs:	16mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	47 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1.874 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	135W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DPAK
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
