STP110N7F6

Part No :: STP110N7F6

Manufacturer: STMicroelectronics

Description: MOSFET N-CHANNEL 68V 110A TO220

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STP110N7F6 PDF

Availability: 1211 pieces

Current price of STP110N7F6 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STP110N7F6 Specifications

Type	Description
Series:	STripFET™ F6
Package:	Tube
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	68 V
Current - Continuous Drain (Id) @ 25°C:	110A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	6.5mOhm @ 55A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	100 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	5850 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	176W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220
Package / Case:	TO-220-3
