NVMFS6H800NLWFT1G

NVMFS6H800NLWFT1G Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	80 V
Current - Continuous Drain (Id) @ 25°C:	30A (Ta), 224A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	1.9mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	2V @ 330µA
Gate Charge (Qg) (Max) @ Vgs:	112 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	6900 pF @ 40 V
FET Feature:	-
Power Dissipation (Max):	3.9W (Ta), 214W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	5-DFN (5x6) (8-SOFL)
Package / Case:	8-PowerTDFN, 5 Leads
