MCU45P03A-TP

Part No :: MCU45P03A-TP

Manufacturer: Micro Commercial Components (MCC)

Description: P-CHANNEL MOSFET, DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: MCU45P03A-TP PDF

Availability: 0 pieces

Current price of MCU45P03A-TP is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MCU45P03A-TP Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	45A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	-
Rds On (Max) @ Id, Vgs:	7mOhm @ 20A, 20V
Vgs(th) (Max) @ Id:	2.8V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	40 nC @ 10 V
Vgs (Max):	±25V
Input Capacitance (Ciss) (Max) @ Vds:	2152 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	75W
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D-PAK
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
