FQB9N08TM

Part No :: FQB9N08TM

Manufacturer: VIGOR

Description: MOSFET N-CH 80V 9.3A D2PAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: FQB9N08TM PDF

Availability: 7169 pieces

Current price of FQB9N08TM is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

FQB9N08TM Specifications

Type	Description
Series:	QFET®
Package:	Bulk
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	80 V
Current - Continuous Drain (Id) @ 25°C:	9.3A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	210mOhm @ 4.65A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	7.7 nC @ 10 V
Vgs (Max):	±25V
Input Capacitance (Ciss) (Max) @ Vds:	250 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	3.75W (Ta), 40W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D²PAK (TO-263AB)
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
