IRLB3036PBF

Part No :: IRLB3036PBF

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 60V 195A TO220AB

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRLB3036PBF PDF

Availability: 0 pieces

Current price of IRLB3036PBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRLB3036PBF Specifications

Type	Description
Series:	HEXFET®
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	195A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	2.4mOhm @ 165A, 10V
Vgs(th) (Max) @ Id:	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	140 nC @ 4.5 V
Vgs (Max):	±16V
Input Capacitance (Ciss) (Max) @ Vds:	11210 pF @ 50 V
FET Feature:	-
Power Dissipation (Max):	380W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220AB
Package / Case:	TO-220-3
