MCQ12N06-TP

Part No :: MCQ12N06-TP

Manufacturer: Micro Commercial Components (MCC)

Description: MOSFET N-CH 60V 12A 8SOP

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: MCQ12N06-TP PDF

Availability: 3440 pieces

Current price of MCQ12N06-TP is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MCQ12N06-TP Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	12A (Tj)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	9mOhm @ 12A, 10V
Vgs(th) (Max) @ Id:	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	31 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1988 pF @ 30 V
FET Feature:	-
Power Dissipation (Max):	3.1W
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-SOP
Package / Case:	8-SOIC (0.154", 3.90mm Width)
