YJL3400A-F2-0000HF

Part No :: YJL3400A-F2-0000HF

Manufacturer

Description: N-CH MOSFET 30V 5.6A SOT-23-3L

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: YJL3400A-F2-0000HF PDF

Availability: 0 pieces

Current price of YJL3400A-F2-0000HF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

YJL3400A-F2-0000HF Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	5.6A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	2.5V, 10V
Rds On (Max) @ Id, Vgs:	25mOhm @ 5.6A, 10V
Vgs(th) (Max) @ Id:	1.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	17.25 nC @ 10 V
Vgs (Max):	±12V
Input Capacitance (Ciss) (Max) @ Vds:	630 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	1.2W (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	SOT-23
Package / Case:	TO-236-3, SC-59, SOT-23-3
