TJ60S06M3L,LXHQ

Part No :: TJ60S06M3L,LXHQ

Manufacturer: Toshiba Electronic Devices and Storage Corporation

Description: MOSFET P-CH 60V 60A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: TJ60S06M3L,LXHQ PDF

Availability: 8972 pieces

Current price of TJ60S06M3L,LXHQ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TJ60S06M3L,LXHQ Specifications

Type	Description
Series:	U-MOSVI
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	60A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	6V, 10V
Rds On (Max) @ Id, Vgs:	11.2mOhm @ 30A, 10V
Vgs(th) (Max) @ Id:	3V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	156 nC @ 10 V
Vgs (Max):	+10V, -20V
Input Capacitance (Ciss) (Max) @ Vds:	7760 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	100W (Tc)
Operating Temperature:	175°C
Mounting Type:	Surface Mount
Supplier Device Package:	DPAK+
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
