IPB80N04S306ATMA1

Part No :: IPB80N04S306ATMA1

Manufacturer: VIGOR

Description: OPTLMOS N-CHANNEL POWER MOSFET

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IPB80N04S306ATMA1 PDF

Availability: 0 pieces

Unit Price: ~~$0.72000~~

Current price of IPB80N04S306ATMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IPB80N04S306ATMA1 Specifications

Type	Description
Series:	OptiMOS™
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	40 V
Current - Continuous Drain (Id) @ 25°C:	80A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	5.4mOhm @ 80A, 10V
Vgs(th) (Max) @ Id:	4V @ 52µA
Gate Charge (Qg) (Max) @ Vgs:	47 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3.25 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	100W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TO263-3-2
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB

Please confirm the specifications of the products when ordering.
