C2M0160120D

Part No :: C2M0160120D

Manufacturer: Wolfspeed - a Cree company

Description: SICFET N-CH 1200V 19A TO247-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: C2M0160120D PDF

Availability: 577 pieces

Unit Price: ~~$7.81000~~

Current price of C2M0160120D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

C2M0160120D Specifications

Type	Description
Series:	Z-FET™
Package:	Tube
Part Status:	Not For New Designs
FET Type:	N-Channel
Technology:	SiCFET (Silicon Carbide)
Drain to Source Voltage (Vdss):	1200 V
Current - Continuous Drain (Id) @ 25°C:	19A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	20V
Rds On (Max) @ Id, Vgs:	196mOhm @ 10A, 20V
Vgs(th) (Max) @ Id:	2.5V @ 500µA
Gate Charge (Qg) (Max) @ Vgs:	32.6 nC @ 20 V
Vgs (Max):	+25V, -10V
Input Capacitance (Ciss) (Max) @ Vds:	527 pF @ 800 V
FET Feature:	-
Power Dissipation (Max):	125W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-247-3
Package / Case:	TO-247-3

Please confirm the specifications of the products when ordering.
