IPN70R600P7SATMA1

Part No :: IPN70R600P7SATMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 700V 8.5A SOT223

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IPN70R600P7SATMA1 PDF

Availability: 1252 pieces

Unit Price: ~~$0.82000~~

Current price of IPN70R600P7SATMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IPN70R600P7SATMA1 Specifications

Type	Description
Series:	CoolMOS™ P7
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	700 V
Current - Continuous Drain (Id) @ 25°C:	8.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	600mOhm @ 1.8A, 10V
Vgs(th) (Max) @ Id:	3.5V @ 90µA
Gate Charge (Qg) (Max) @ Vgs:	10.5 nC @ 10 V
Vgs (Max):	±16V
Input Capacitance (Ciss) (Max) @ Vds:	364 pF @ 400 V
FET Feature:	-
Power Dissipation (Max):	6.9W (Tc)
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-SOT223
Package / Case:	TO-261-3

Please confirm the specifications of the products when ordering.
