STD14NM50NAG

Part No :: STD14NM50NAG

Manufacturer: STMicroelectronics

Description: MOSFET N-CH 500V 12A DPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STD14NM50NAG PDF

Availability: 2009 pieces

Unit Price: ~~$1.78000~~

Current price of STD14NM50NAG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STD14NM50NAG Specifications

Type	Description
Series:	Automotive, AEC-Q101, MDmesh™ II
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	12A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	320mOhm @ 6A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	27 nC @ 10 V
Vgs (Max):	±25V
Input Capacitance (Ciss) (Max) @ Vds:	816 pF @ 50 V
FET Feature:	-
Power Dissipation (Max):	90W
Operating Temperature:	150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DPAK
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63

Please confirm the specifications of the products when ordering.
