AO7401

Part No :: AO7401

Manufacturer: Alpha and Omega Semiconductor, Inc.

Description: MOSFET P-CH 30V 1.4A SC70-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: AO7401 PDF

Availability: 2001 pieces

Unit Price: ~~$0.43000~~

Current price of AO7401 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AO7401 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	1.4A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	2.5V, 10V
Rds On (Max) @ Id, Vgs:	150mOhm @ 1.2A, 10V
Vgs(th) (Max) @ Id:	1.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	5.06 nC @ 4.5 V
Vgs (Max):	±12V
Input Capacitance (Ciss) (Max) @ Vds:	409 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	350mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	SC-70-3
Package / Case:	SC-70, SOT-323

Please confirm the specifications of the products when ordering.
