BSC032N03S

Image is for reference,
please contact us to get the real picture

Part No :: BSC032N03S

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 30V 23A/100A TDSON

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BSC032N03S PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of BSC032N03S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BSC032N03S Specifications

Type	Description
Series:	OptiMOS™
Package:	Tape & Reel (TR)
Part Status:	Discontinued at Digi-Key
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	23A (Ta), 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	3.2mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	2V @ 70µA
Gate Charge (Qg) (Max) @ Vgs:	39 nC @ 5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	5080 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	2.8W (Ta), 78W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TDSON-8-1
Package / Case:	8-PowerTDFN

Please confirm the specifications of the products when ordering.
