STP5NK65Z

Part No :: STP5NK65Z

Manufacturer: STMicroelectronics

Description: MOSFET N-CH 650V 5A TO220

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STP5NK65Z PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of STP5NK65Z is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STP5NK65Z Specifications

Type	Description
Series:	SuperMESH™
Package:	Tube
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	650 V
Current - Continuous Drain (Id) @ 25°C:	5A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	1.8Ohm @ 2.1A, 10V
Vgs(th) (Max) @ Id:	4.5V @ 50µA
Gate Charge (Qg) (Max) @ Vgs:	35 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	680 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	85W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220
Package / Case:	TO-220-3
