STU40N2LH5

Part No :: STU40N2LH5

Manufacturer: STMicroelectronics

Description: MOSFET N-CH 25V 40A IPAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STU40N2LH5 PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of STU40N2LH5 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STU40N2LH5 Specifications

Type	Description
Series:	STripFET™ V
Package:	Tube
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	25 V
Current - Continuous Drain (Id) @ 25°C:	40A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	5V, 10V
Rds On (Max) @ Id, Vgs:	12.4mOhm @ 20A, 10V
Vgs(th) (Max) @ Id:	1V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	6.3 nC @ 5 V
Vgs (Max):	±22V
Input Capacitance (Ciss) (Max) @ Vds:	700 pF @ 20 V
FET Feature:	-
Power Dissipation (Max):	35W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	I-PAK
Package / Case:	TO-251-3 Short Leads, IPak, TO-251AA
