APT20F50S

Part No :: APT20F50S

Manufacturer: Microsemi

Description: MOSFET N-CH 500V 20A D3PAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: APT20F50S PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of APT20F50S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

APT20F50S Specifications

Type	Description
Series:	POWER MOS 8™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	300mOhm @ 10A, 10V
Vgs(th) (Max) @ Id:	5V @ 500µA
Gate Charge (Qg) (Max) @ Vgs:	75 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	2950 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	290W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D3Pak
Package / Case:	TO-268-3, D³Pak (2 Leads + Tab), TO-268AA

Please confirm the specifications of the products when ordering.
