| Type | Description |
|---|---|
| Series: | Polar™ |
| Package: | Tube |
| Part Status: | Active |
| FET Type: | N-Channel |
| Technology: | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss): | 1000 V |
| Current - Continuous Drain (Id) @ 25°C: | 500mA (Tc) |
| Drive Voltage (Max Rds On, Min Rds On): | 10V |
| Rds On (Max) @ Id, Vgs: | 30Ohm @ 250mA, 10V |
| Vgs(th) (Max) @ Id: | 4V @ 50µA |
| Gate Charge (Qg) (Max) @ Vgs: | 8.1 nC @ 10 V |
| Vgs (Max): | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds: | 196 pF @ 25 V |
| FET Feature: | - |
| Power Dissipation (Max): | 50W (Tc) |
| Operating Temperature: | -55°C ~ 150°C (TJ) |
| Mounting Type: | Through Hole |
| Supplier Device Package: | TO-220AB |
| Package / Case: | TO-220-3 |
| Quantity | Unit Price | Ext. Price |
|---|
Current price of IXTP05N100P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
