| Type | Description |
|---|---|
| Series: | - |
| Package: | Tape & Reel (TR) |
| Part Status: | Obsolete |
| FET Type: | N-Channel |
| Technology: | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss): | 250 V |
| Current - Continuous Drain (Id) @ 25°C: | 400mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On): | 2.5V, 4V |
| Rds On (Max) @ Id, Vgs: | 5.7Ohm @ 200mA, 4V |
| Vgs(th) (Max) @ Id: | - |
| Gate Charge (Qg) (Max) @ Vgs: | 3.7 nC @ 4 V |
| Vgs (Max): | ±10V |
| Input Capacitance (Ciss) (Max) @ Vds: | 80 pF @ 25 V |
| FET Feature: | - |
| Power Dissipation (Max): | 750mW (Ta) |
| Operating Temperature: | 150°C (TJ) |
| Mounting Type: | Through Hole |
| Supplier Device Package: | TO-92 |
| Package / Case: | TO-226-3, TO-92-3 (TO-226AA) (Formed Leads) |
| Quantity | Unit Price | Ext. Price |
|---|
Current price of 2SK4150TZ-E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
