| Type | Description |
|---|---|
| Series: | - |
| Package: | Tape & Reel (TR)Cut Tape (CT) |
| Part Status: | Obsolete |
| FET Type: | N-Channel |
| Technology: | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss): | 30 V |
| Current - Continuous Drain (Id) @ 25°C: | 12.5A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On): | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs: | 50mOhm @ 8A, 10V |
| Vgs(th) (Max) @ Id: | 3V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs: | 7 nC @ 4.5 V |
| Vgs (Max): | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds: | 270 pF @ 25 V |
| FET Feature: | - |
| Power Dissipation (Max): | 12.5W (Tc) |
| Operating Temperature: | 150°C (TJ) |
| Mounting Type: | Surface Mount |
| Supplier Device Package: | TO-252, (D-Pak) |
| Package / Case: | TO-252-3, DPak (2 Leads + Tab), SC-63 |
| Quantity | Unit Price | Ext. Price |
|---|
Current price of TSM500N03CP ROG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
