MG12100D-BA1MM

Part No :: MG12100D-BA1MM

Manufacturer: Wickmann / Littelfuse

VIGOR # :: 4619658

Description: IGBT MODULE 1200V 160A 1000W D3

Catalog: Transistors - IGBTs - Modules

DataSheet: MG12100D-BA1MM PDF

Country of origin: -

Date code: -

MG12100D-BA1MM Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
IGBT Type:	-
Configuration:	Half Bridge
Voltage - Collector Emitter Breakdown (Max):	1200 V
Current - Collector (Ic) (Max):	160 A
Power - Max:	1000 W
Vce(on) (Max) @ Vge, Ic:	1.8V @ 15V, 100A (Typ)
Current - Collector Cutoff (Max):	1 mA
Input Capacitance (Cies) @ Vce:	8.58 nF @ 25 V
Input:	Standard
NTC Thermistor:	No
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Chassis Mount
Package / Case:	Module
Supplier Device Package:	D3
