Part No :

NGTB30N135IHR1WG

Manufacturer
Sanyo Semiconductor/ON Semiconductor
VIGOR # :

2914563

Description
IGBT 1350V 30A TO247
Catalog
Transistors - IGBTs - Single
DataSheet
NGTB30N135IHR1WG PDF
Country of origin
-
Date code
-
ads
Type Description
Series:-
Package:Tube
Part Status:Last Time Buy
IGBT Type:Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):1350 V
Current - Collector (Ic) (Max):60 A
Current - Collector Pulsed (Icm):120 A
Vce(on) (Max) @ Vge, Ic:3V @ 15V, 30A
Power - Max:394 W
Switching Energy:630µA (off)
Input Type:Standard
Gate Charge:220 nC
Td (on/off) @ 25°C:-/200ns
Test Condition:600V, 30A, 10Ohm, 15V
Reverse Recovery Time (trr):-
Operating Temperature:-40°C ~ 175°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-247-3
Supplier Device Package:TO-247-3
