NGTB45N60SWG

Part No :: NGTB45N60SWG

Manufacturer: VIGOR

VIGOR # :: 2914832

Description: 600V/45A IGBT

Catalog: Transistors - IGBTs - Single

DataSheet: NGTB45N60SWG PDF

Country of origin: -

Date code: -

NGTB45N60SWG Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
IGBT Type:	Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):	600 V
Current - Collector (Ic) (Max):	90 A
Current - Collector Pulsed (Icm):	180 A
Vce(on) (Max) @ Vge, Ic:	2.4V @ 15V, 45A
Power - Max:	250 W
Switching Energy:	550µJ (off)
Input Type:	Standard
Gate Charge:	134 nC
Td (on/off) @ 25°C:	70ns/144ns
Test Condition:	400V, 45A, 10Ohm, 15V
Reverse Recovery Time (trr):	376 ns
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-247-3
Supplier Device Package:	TO-247-3
