NGTB40N120FL2WAG

Product image
Product thumb
Part No :

NGTB40N120FL2WAG

Manufacturer
Sanyo Semiconductor/ON Semiconductor
VIGOR # :

2914898

Description
IGBT FIELD STOP 1200V 160A TO247
Catalog
Transistors - IGBTs - Single
DataSheet
NGTB40N120FL2WAG PDF
Country of origin
-
Date code
-
ads
NGTB40N120FL2WAG Specifications
Type Description
Series:-
Package:Tube
Part Status:Last Time Buy
IGBT Type:Field Stop
Voltage - Collector Emitter Breakdown (Max):1200 V
Current - Collector (Ic) (Max):160 A
Current - Collector Pulsed (Icm):160 A
Vce(on) (Max) @ Vge, Ic:2.4V @ 15V, 40A
Power - Max:536 W
Switching Energy:1.7mJ (on), 1.1mJ (off)
Input Type:Standard
Gate Charge:313 nC
Td (on/off) @ 25°C:30ns/145ns
Test Condition:600V, 40A, 10Ohm, 15V
Reverse Recovery Time (trr):240 ns
Operating Temperature:-55°C ~ 175°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-247-4
Supplier Device Package:TO-247-4L
