NGTB40N120SWG

Part No :: NGTB40N120SWG

Manufacturer: VIGOR

VIGOR # :: 2915055

Description: IGBT

Catalog: Transistors - IGBTs - Single

DataSheet: NGTB40N120SWG PDF

Country of origin: -

Date code: -

NGTB40N120SWG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
IGBT Type:	Trench
Voltage - Collector Emitter Breakdown (Max):	1.2 V
Current - Collector (Ic) (Max):	80 A
Current - Collector Pulsed (Icm):	200 A
Vce(on) (Max) @ Vge, Ic:	2.4V @ 15V, 40A
Power - Max:	535 W
Switching Energy:	3.4mJ (on), 1.1mJ (off)
Input Type:	Standard
Gate Charge:	313 nC
Td (on/off) @ 25°C:	116ns/286ns
Test Condition:	600V, 40A, 10Ohm, 15V
Reverse Recovery Time (trr):	240 ns
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-247-3
Supplier Device Package:	TO-247-3
