HGTD1N120BNS9A

Part No :: HGTD1N120BNS9A

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 2915158

Description: IGBT 1200V 5.3A 60W TO252AA

Catalog: Transistors - IGBTs - Single

DataSheet: HGTD1N120BNS9A PDF

Country of origin: -

Date code: -

HGTD1N120BNS9A Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
IGBT Type:	NPT
Voltage - Collector Emitter Breakdown (Max):	1200 V
Current - Collector (Ic) (Max):	5.3 A
Current - Collector Pulsed (Icm):	6 A
Vce(on) (Max) @ Vge, Ic:	2.9V @ 15V, 1A
Power - Max:	60 W
Switching Energy:	70µJ (on), 90µJ (off)
Input Type:	Standard
Gate Charge:	14 nC
Td (on/off) @ 25°C:	15ns/67ns
Test Condition:	960V, 1A, 82Ohm, 15V
Reverse Recovery Time (trr):	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	TO-252-3, DPak (2 Leads + Tab), SC-63
Supplier Device Package:	TO-252AA
