STGWA40M120DF3

Product image
Product thumb
Part No :

STGWA40M120DF3

Manufacturer
STMicroelectronics
VIGOR # :

2915441

Description
IGBT 1200V 80A 468W TO-247-3
Catalog
Transistors - IGBTs - Single
DataSheet
STGWA40M120DF3 PDF
Country of origin
-
Date code
-
ads
STGWA40M120DF3 Specifications
Type Description
Series:-
Package:Tube
Part Status:Active
IGBT Type:Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):1200 V
Current - Collector (Ic) (Max):80 A
Current - Collector Pulsed (Icm):160 A
Vce(on) (Max) @ Vge, Ic:2.3V @ 15V, 40A
Power - Max:468 W
Switching Energy:1.03mJ (on), 480µJ (off)
Input Type:Standard
Gate Charge:125 nC
Td (on/off) @ 25°C:35ns/140ns
Test Condition:600V, 40A, 10Ohm, 15V
Reverse Recovery Time (trr):355 ns
Operating Temperature:-55°C ~ 175°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-247-3
Supplier Device Package:TO-247
